FLOWLUX PURE BQKY

Evolved for the Better
Flowlux Pure BQKY 4279 Mining modules generate mixed bed deionized water through electrodeionization and are specifically designed for mining applications. Flowlux Pure BQKY 4279 Mining modules consistently deliver maximum reliability and superior performance for power, HPI/CPI, general electronics and laboratory applications without regeneration downtime.



Flowlux Pure BQKY 4279 Module Model No:67KF8   Operating Environment ■     Installation should be indoors with no direct sun light and should have a maximum ambient room temperature of 113˚F (45˚C).  Quality Assurance Standards ■    CE marked. Each module is factory tested to meet strict industry standards and is manufactured in an ISO 9001 and ISO 14000 quality and environmental management system.  Specifications ■ Product Flow min. gpm (m3/hr) 2.0 (0.44) ■ Product Flow nominal gpm (m3/hr) 3.5 (0.64) ■ Product Flow max. gpm (m3/hr) 4.0 (0.78) ■ Product Weight lbs (kg) 182(75) ■ Product Weight lbs (kg) 120 (65)

Features   ■ Cost effective CPVC spacers for Mining EDI ■    Double O-ring seal guarantees leak-free operation ■ Generate mixed-bed quality deionized water without the use of chemicals ■ No need for acid/caustic, neutralization system or exchangable DI tanks ■ Continuous production instead of batch, with consistent quality ■ Superior electrical isolation ■ 100 psi (7 bar), 113˚F (45˚C) continuous operation ■ Proprietary all-filled concentrating compartments eliminate recirculation pump and brine injection ■ Significantly lower operating costs, than conventional ion exchange           Operational Data Model Number and Product Flow Product Flow nominal gpm (m3/hr) Product Flow max. gpm (m3/hr) Shipping Weight lbs (kg) Operating Weight lbs (kg) 67KF8  / 2.0 (0.44) 3.5 (0.64) 4.0 (0.78) 182(75) 120 (65)
